Tractor · 2005Unverified
Farm Pro 4010
Farm Pro 4010 — Jinma built · 40 hp. Reference specifications; pending source verification.
The Farm Pro 4010 is a tractor with a rated power of 40 hp, positioning it at the lighter end of its class. It was manufactured from 2005 to 2012. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine and four-wheel drive, paired with an 8-speed gearbox. Its operating weight ranges from 4270 to 4632 pounds.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
4270 to 4632 pounds
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
40 hp
Recorded weight
1936 kg
Transmissions
8-speed
Production years
2005-2012
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorFarm ProReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
SteeringpowerReference
ROPS canopyReference
Engine
2.9L 3-cyl dieselReference
Engine29.8 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke105 x 110 mmReference
Power29.8 kWReference
Rated RPM2200Reference
Oil capacity6.0 LReference
Coolant capacity12.5 LReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
Oil capacity31.0 LReference
Capacities
Fuel34.8 LReference
PTO & Hydraulics
Hydraulic system12.0 LReference
Capacity12.0 LReference
Total flow18.0 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)683 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540/720Reference
Dimensions
Wheelbase194 cmReference
Weight4270 to 4632 poundsReference
Front tire7.5-16Reference
Rear tire11.2-28Reference
Ag front7.5-16Reference
Ag rear11.2-28Reference
Length382 cmReference
Width162 cmReference
Height206 cmReference
Shipping weight1936 kgReference
Operating weight2101 kgReference
Ground clearance32 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
