Tractor · 2005Unverified
Farm Pro 6010
Farm Pro 6010 — Jinma built · 60 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Weight
5002 to 5402 pounds
Hover a source tag to verify
Overview
DistributorFarm ProReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
SteeringpowerReference
ROPS canopyReference
Engine
3.7L 4-cyl dieselReference
Engine44.7 kWReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.7 LReference
Bore/Stroke105 x 117 mmReference
Power44.7 kWReference
Rated RPM2300Reference
Oil capacity7.9 LReference
Coolant capacity14.4 LReference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
Oil capacity35.0 LReference
Capacities
Fuel46.6 LReference
PTO & Hydraulics
Hydraulic system17.5 LReference
Capacity17.5 LReference
Total flow32.2 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1019 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540Reference
Dimensions
Wheelbase205 cmReference
Weight5002 to 5402 poundsReference
Front tire8.3-20Reference
Rear tire12.4-28Reference
Ag front8.3-20Reference
Ag rear12.4-28Reference
Length394 cmReference
Width167 cmReference
Height248 cmReference
Shipping weight2268 kgReference
Operating weight2450 kgReference
Ground clearance38 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
