Farm Pro 7040
Farm Pro 7040 — Jinma built · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
6999 to 7507 pounds
Hover a source tag to verify
Overview
DistributorFarm ProReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
SteeringpowerReference
Cab with heat and A/CReference
Engine
Perkins 4.0L 4-cyl dieselReference
Engine52.2 kWReference
PerkinsReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
Power52.2 kWReference
Rated RPM2200Reference
Oil capacity17.0 LReference
Coolant capacity15.0 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Oil capacity40.0 LReference
Capacities
Fuel78.0 LReference
PTO & Hydraulics
Hydraulic system21.0 LReference
Capacity21.0 LReference
Pressure160.7 barReference
Total flow34.1 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1223 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540Reference
Dimensions
Wheelbase145 cmReference
Weight6999 to 7507 poundsReference
Front tire8.3Reference
Rear tire14.9Reference
Ag front8.3 - 24Reference
Ag rear14.9 - 30Reference
Length401 cmReference
Width192 cmReference
Height (cab)249 cmReference
Height (exhaust)256 cmReference
Shipping weight3174 kgReference
Operating weight3405 kgReference
Ground clearance34 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
