Tractor · 2005Unverified
Farm Pro 7510
Farm Pro 7510 — Jinma built · 75 hp. Reference specifications; pending source verification.
The Farm Pro 7510 is a tractor with a rated output of 75 hp, positioning it approximately in the middle of its class in terms of power. Manufactured from 2005 to 2012, this tractor features a 4-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and an 8-speed gearbox. Its listed weight ranges from 6525 to 7032 pounds. The 7510 is designed for use on areas of approximately up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
6525 to 7032 pounds
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
75 hp
Recorded weight
2959 kg
Transmissions
8-speed
Production years
2005-2012
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorFarm ProReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
SteeringpowerReference
ROPS canopyReference
Engine
4.0L 4-cyl dieselReference
Engine55.9 kWReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 125 mmReference
Power55.9 kWReference
Rated RPM2300Reference
Oil capacity11.0 LReference
Coolant capacity15.9 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Oil capacity47.8 LReference
Capacities
Fuel54.9 LReference
PTO & Hydraulics
Hydraulic system22.1 LReference
Capacity22.1 LReference
Total flow35.2 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1264 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase223 cmReference
Weight6525 to 7032 poundsReference
Front tire8.3-24Reference
Rear tire14.9-30Reference
Ag front8.3-24Reference
Ag rear14.9-30Reference
Length405 cmReference
Width192 cmReference
Height278 cmReference
Shipping weight2959 kgReference
Operating weight3189 kgReference
Ground clearance34 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
