Tractor · 2005Unverified
Farm Pro 8220
Farm Pro 8220 — Jinma built · 82 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
82 hp
Weight
8267 to 8796 pounds
Hover a source tag to verify
Overview
DistributorFarm ProReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
SteeringpowerReference
Cab with heat and A/CReference
Engine
Perkins 4.0L 4-cyl dieselReference
Engine61.1 kWReference
PerkinsReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
Power61.1 kWReference
Rated RPM2400Reference
Oil capacity17.0 LReference
Coolant capacity15.0 LReference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
Oil capacity38.0 LReference
Capacities
Fuel149.9 LReference
PTO & Hydraulics
Hydraulic system17.0 LReference
Capacity17.0 LReference
Pressure160.7 barReference
Total flow34.1 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1356 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540 / 1000Reference
Dimensions
Wheelbase162 cmReference
Weight8267 to 8796 poundsReference
Front tire11.2Reference
Rear tire16.9Reference
Ag front11.2 - 24Reference
Ag rear16.9 - 34Reference
Length439 cmReference
Width203 cmReference
Height (cab)256 cmReference
Height (exhaust)279 cmReference
Shipping weight3749 kgReference
Operating weight3989 kgReference
Ground clearance37 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
