Tractor · 1956Unverified
Farmall 130
Farmall 130 — Row-Crop tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Max power
14.8 kW
Weight
1270 kg
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Row-Crop tractorReference
Total built9,197Reference
Original price$2000 (1958)Reference
Two-wheel driveReference
SteeringmanualReference
Differential mechanical contracting band brakesReference
Open operator station.Reference
Variants
130row-cropReference
130 Hi-Clearhigh-cropReference
130similar International Harvester modelReference
Engine
International Harvester 2.0L 4-cyl gasolineReference
Fuel tank41.6 LReference
Drawbar (tested)14.8 kWReference
Belt (tested)16.6 kWReference
International Harvester C-123Reference
gasolineReference
4-cylinderReference
liquid-cooled vertical I-headReference
Displacement2.0 LReference
Bore/Stroke79 x 102 mmReference
Air cleaneroil bathReference
Compression6.8:1Reference
Rated RPM1400Reference
Firing order1-3-4-2Reference
Starter volts6Reference
Oil capacity4.7 LReference
Coolant capacity14.2 LReference
Belt power (max)16.6 kWReference
Max power14.8 kWReference
Transmission
4-speed sliding gearReference
Typesliding gearReference
Gears4 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
TypeIH Fast-Hitch (1-arm)Reference
Rear PTO Type540Reference
Dimensions
Wheelbase180 cmReference
Weight1270 kgReference
Front tire5.00x15Reference
Rear tire9.00x24Reference
Ag front5.00x15Reference
Ag rear9.00x24Reference
Length271 cmReference
Width142 cmReference
Height (steering wheel)165 cmReference
Operating weight1270 kgReference
Ballasted weight2109 kgReference
Ground clearance55 cmReference
Ground clearance68 cmReference
Front tread111 to 162 cmReference
Rear tread101 to 172 cmReference
Farmall 130 attachments
front-end loaderReference
130 Serial Number Location
Serial number plate on the left side of the clutch housing.Reference
130 Serial Numbers
1956501Reference
19571120Reference
19588363Reference
Final10209Reference
FAQ: How to read a serial number table.Reference
Test results
Gasoline 4-speed 2WDApril 25 - May 7, 1957Link: Nebraska Tractor Test 617 fileReference
Belt fuel use (max)6.8 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1340 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
