Tractor · 1958Unverified
Farmall 140
Farmall 140 · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Max power
15.8 kW
Weight
1360 kg
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Total built66,290Reference
The Farmall 140 was restyled in late 1963 at tractor serial number 23301. The new style was to match the Farmall 404 and 504 tractors then in production.Reference
Two-wheel driveReference
SteeringmanualReference
Differential contracting band brakesReference
Open operator station.Reference
Variants
International 140IH versionReference
Farmall 140utilityReference
140 Hi-Clearhigh-cropReference
Engine
International Harvester 2.0L 4-cyl gasolineReference
Fuel tank41.6 LReference
Drawbar (claimed)12.7 kWReference
Plows1Reference
Drawbar (tested)15.8 kWReference
Belt (tested)17.2 kWReference
International Harvester C-123Reference
gasolineReference
4-cylinderReference
liquid-cooled vertical I-headReference
Displacement2.0 LReference
Bore/Stroke79 x 102 mmReference
Air cleaneroil bathReference
Compression6.94:1Reference
Rated RPM1400Reference
Firing order1-3-4-2Reference
Starter volts6 (early)Reference
Starter volts12 (late)Reference
Oil capacity4.7 LReference
Coolant capacity14.4 LReference
Belt power (max)17.2 kWReference
Max power15.8 kWReference
Transmission
4-speed sliding gearReference
Typesliding gearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)15.7 kWReference
TypeIH Fast Hitch (one-point)Reference
Rear PTOtransmissionReference
Rear PTO Type540Reference
Dimensions
Wheelbase180 cmReference
Weight1360 kgReference
Front tire5.00-15Reference
Rear tire11.2-24Reference
Ag front5.00-15Reference
Ag rear11.2-24Reference
Length271 cmReference
Height210 cmReference
Height (steering wheel)165 cmReference
Operating weight1360 kgReference
Ballasted weight2188 kgReference
Farmall 140 attachments
front-end loaderReference
140 Serial Number Location
Serial number plate on the left side of the tractor, on the clutch housing.Reference
140 Serial Numbers
1958501Reference
19592011Reference
19608082Reference
196111168Reference
196216637Reference
196321181Reference
196425387Reference
196528408Reference
196631285Reference
196734818Reference
196837352Reference
196939906Reference
197042300Reference
197144424Reference
197246605Reference
197348507Reference
197450720Reference
197554273Reference
197657773Reference
197760839Reference
197863111Reference
197964544Reference
FAQ: How to read a serial number table.Reference
Electrical
Groundpositive (6V)Reference
Groundnegative (12V)Reference
Charging systemgenerator (early)Reference
Charging systemalternator (late)Reference
Battery volts6 (early)Reference
Battery volts12 (late)Reference
Test results
Gasoline 4-speed 2WDSeptember 3 - 18, 1958Link: Nebraska Tractor Test 666 fileReference
Belt fuel use (max)7.6 l/hourReference
Drawbar performanceReference
Fuel use7.6 l/hourReference
Gear 2 used for power test.Reference
Max pull1637 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
