Tractor · 1954Unverified
Farmall 200
Farmall 200 — Row-Crop tractor · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Max power
15.6 kW
Weight
1606 kg
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Row-Crop tractorReference
Original price was $1,970 in 1956Reference
Two-wheel driveReference
SteeringmanualReference
Differential mechanical dry disc brakesReference
Open operator station.Reference
Engine
International Harvester 2.0L 4-cyl gasolineReference
Drawbar (tested)15.6 kWReference
Belt (tested)18.0 kWReference
International Harvester C123Reference
gasolineReference
4-cylinderReference
liquid-cooled vertical I-headReference
Displacement2.0 LReference
Bore/Stroke79 x 102 mmReference
Air cleaneroil bathReference
Compression6.5:1Reference
Rated RPM1400Reference
Firing order1-3-4-2Reference
Starter volts6Reference
Oil capacity4.7 LReference
Belt power (max)18.0 kWReference
Max power15.6 kWReference
Transmission
4-speed sliding gearReference
Typesliding gearReference
Gears4 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase208 cmReference
Weight1606 kgReference
Front tire5.00-15Reference
Rear tire10-36Reference
Ag front5.00-15Reference
Ag rear10-36Reference
Front tread16 to 31 cmReference
Rear tread121 to 203 cmReference
200 Serial Number Location
Clutch housing, right sideReference
200 Serial Numbers
1954501Reference
19551032Reference
195610904Reference
FAQ: How to read a serial number table.Reference
Test results
Gasoline 4-speed 2WDApril 18 - 29, 1955Link: Nebraska Tractor Test 536 fileReference
Belt fuel use (max)9.1 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1436 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
