Tractor · 1956Unverified
Farmall 350
Farmall 350 — Row-Crop tractor · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Max power
26.3 kW
Weight
5331 to 5475 pounds
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Row-Crop tractorReference
Built in Rock Island, Illinois, USAReference
Original price was $3,100 in 1958Reference
Two-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Open operator station.Reference
Variants
IH 350utility tractorReference
Farmall 350row-cropReference
Farmall 350 Hi-Clearhigh-crop tractorReference
Engine
Continental 3.2L 4-cyl dieselReference
International Harvester 2.9L 4-cyl gasolineReference
International Harvester 2.9L 4-cyl LP gasReference
Gasoline Fuel tank64.3 LReference
Diesel Fuel tank68.1 LReference
LP gas Fuel tank69.6 LReference
Drawbar (tested)26.3 kWReference
Belt (tested)29.3 kWReference
Continental D193Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.2 LReference
Bore/Stroke95 x 111 mmReference
Air cleaneroil bathReference
Compression16.87:1Reference
Rated RPM1750Reference
Starter volts12Reference
Coolant capacity16.3 LReference
International Harvester C175Reference
gasolineReference
liquid-cooled vertical I-headReference
Displacement2.9 LReference
Bore/Stroke92 x 108 mmReference
Compression7.0:1Reference
Starter volts6Reference
Coolant capacity18.0 LReference
LP gasReference
Compression9.0:1Reference
Rated RPM2000Reference
Belt power (max)28.8 kWReference
Max power26.3 kWReference
Belt power (max)29.3 kWReference
Max power26.1 kWReference
Belt power (max)29.3 kWReference
Max power25.7 kWReference
Transmission
5-speed sliding gearReference
10-speed two-speed power shiftReference
Typesliding gearReference
Gears5 forward and 1 reverseReference
Clutchdry discReference
TransmissionTorque AmplifierReference
Typetwo-speed power shiftReference
Gears10 forward and 2 reverseReference
The Torque Amplifier (TA) provides a clutchless shift-on-the-move between normal, direct drive (DD) and the TA. By engaging the TA, tractor ground speed is reduced and torque is increased.Reference
PTO & Hydraulics
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase234 cmReference
Weight5331 to 5475 poundsReference
Front tire5.50-16Reference
Rear tire11.00x38Reference
Ag front5.50-16Reference
Ag rear11.00x38Reference
Ag rear13.6x38Reference
Length345 cmReference
Width210 cmReference
Height (steering wheel)196 cmReference
Ground clearance48 cmReference
Front tread20/42 cmReference
Rear tread121 to 236 cmReference
Diesel2433 kgReference
Gasoline2418 kgReference
LP gas2483 kgReference
Farmall 350 attachments
front-end loaderReference
350 Serial Number Location
Clutch housing, right sideReference
350 Serial Numbers
1956501Reference
19571030Reference
195814674Reference
Final17215Reference
FAQ: How to read a serial number table.Reference
Test results
NTTL 609: diesel Torque Amplifier 2WDReference
NTTL 611: gasoline Torque Amplifier 2WDReference
NTTL 622: LP gas Torque Amplifier 2WDReference
Diesel Torque Amplifier 2WDMarch 18 - April 5, 1957Link: Nebraska Tractor Test 609 fileReference
Belt fuel use (max)9.8 l/hourReference
Drawbar performanceReference
Gear 3-Direct used for power test.Reference
Max pull2739 kgReference
Gear 1-TA used for pull test.Reference
Gasoline Torque Amplifier 2WDApril 1 - 13, 1957Link: Nebraska Tractor Test 611 fileReference
Belt fuel use (max)12.1 l/hourReference
Max pull2928 kgReference
LP gas Torque Amplifier 2WDMay 22 - 29, 1957Link: Nebraska Tractor Test 622 fileReference
Belt fuel use (max)15.5 l/hourReference
Max pull2900 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
