Tractor · 1962Unverified

Farmall A-514

Name: Farmall A-514
Brand: Farmall

Farmall A-514 — Row-Crop tractor · 51 hp. Reference specifications; pending source verification.

The Farmall A-514 is a compact tractor with a rated output of 51 hp, produced between 1962 and 1964. It features a 4-cylinder diesel liquid-cooled engine, paired with a 5-speed gearbox and two-wheel drive. The tractor is intended for use on small to medium-sized plots, with a capacity of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

51 hp

Catalogue coverage

Variants represented

Richest spec table

27 rows

Recorded power

51 hp

Transmissions

5-speed gear

Production years

1962-1964

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFarmall (a part of International Harvester)Reference

Row-Crop tractorReference

Built in Geelong, AustraliaReference

Original price was AUP 1,440 in 1964Reference

The McCormick International FARMALL A-514 was mechanically similar to the British-built B-450 and similar in appearance to the US-built 560. A row-crop tractor, it was available with single front wheel, tricycle front, or adjustable wide front. The A-514 was supplanted by the A-554.Reference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Engine

International Harvester 4.3L 4-cyl dieselReference

Engine37.7 kWReference

International Harvester AD-264Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.3 LReference

Bore/Stroke102 x 133 mmReference

Power37.7 kWReference

Rated RPM1450Reference

Starter typeelectricReference

Transmission

5-speed gearReference

TypegearReference

Gears5 forward and 1 reverseReference

PTO & Hydraulics

Rear TypeIIReference

Dimensions

Front tire6.00-16Reference

Rear tire13.6-38Reference

Ag front6.00-16Reference

Ag rear13.6-38Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
