The Farmall F-137 is a compact tractor model with a rated output of 20 hp, produced from 1961 to 1964. It features a 2-cylinder diesel liquid-cooled engine, which transmits power through a 6-speed gearbox to the two-wheel drive system. The listed weight of the tractor is 1080 kg and it is suitable for working areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1080 kg
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
20 hp
Recorded weight
1080 kg
Transmissions
6-speed gear
Production years
1961-1964
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Row-Crop tractorReference
Built in Saint Dizier, FranceReference
Two-wheel driveReference
Open operator station.Reference
Engine
International Harvester 1.2L 2-cyl dieselReference
Fuel tank37.9 LReference
Engine14.9 kWReference
International Harvester FDD-74Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.2 LReference
Bore/Stroke87 x 102 mmReference
Power14.9 kWReference
Rated RPM1900Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
Dimensions
Wheelbase176 cmReference
Weight1080 kgReference
Front tire4.50-16Reference
Rear tire9-24Reference
Ag front4.50-16Reference
Ag rear9-24Reference
Ag rear10-24Reference
Length259 cmReference
Width143 cmReference
Height156 cmReference
Operating weight1080 kgReference
Ballasted weight1455 kgReference
Ground clearance40 cmReference
Front tread119 to 169 cmReference
Rear tread119 to 180 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
