The Farmall F-235 is a tractor with a rated power of 26 hp, positioning it at the lower end of its class in terms of power output. Produced from 1957 to 1959, the F-235 features a 4-cylinder diesel liquid-cooled engine paired with two-wheel drive and a 4-speed gearbox. Its operating weight is 1655 kg, and it is suitable for operations on areas up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
1655 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
26 hp
Recorded weight
1655 kg
Transmissions
4-speed gear
Production years
1957-1959
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Row-Crop tractorReference
Built in Saint Dizier, FranceReference
Two-wheel driveReference
Open operator station.Reference
Variants
F-235gas row-cropReference
F-235Ddiesel row-cropReference
FU-235utilityReference
Engine
International Harvester 2.0L 4-cyl gasolineReference
International Harvester 2.0L 4-cyl dieselReference
Engine19.4 kWReference
International Harvester FC-123Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke79 x 102 mmReference
Power19.4 kWReference
Rated RPM1650Reference
International Harvester FD-123Reference
dieselReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase231 cmReference
Weight1655 kgReference
Front tire5.00x15Reference
Rear tire10.00x36Reference
Ag front5.00x15Reference
Ag rear10.00x36Reference
Length331 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
