Tractor · 1942Unverified
Farmall HV
Farmall HV — High-Clearance tractor · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
2165 kg
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
High-Clearance tractorReference
Total built863Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
Hrow-cropReference
HVhigh-cropReference
W-4standard treadReference
I-4industrialReference
O-4orchardReference
Engine
International Harvester 2.5L 4-cyl gasolineReference
International Harvester 2.5L 4-cyl distillateReference
International Harvester 2.5L 4-cyl keroseneReference
Drawbar (claimed)14.2 kWReference
Belt (claimed)17.9 kWReference
International Harvester C-152Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke86 x 108 mmReference
Compression5.9:1Reference
Rated RPM1650Reference
Firing order1-3-4-2Reference
Oil capacity5.7 LReference
Coolant capacity15.6 LReference
Sparkplug gap0.635 mmReference
Point gap0.330 mmReference
Intake valve clearance0.432 mmReference
Exhaust valve clearance0.432 mmReference
International HarvesterReference
distillateReference
liquid-cooled vertical I-headReference
Compression4.75:1Reference
keroseneReference
Compression4.5:1Reference
Transmission
5-speed sliding gearReference
Typesliding gearReference
Gears5 forward and 1 reverseReference
Clutchdry discReference
Capacities
Fuel66.2 LReference
Aux. fuel3.3 LReference
PTO & Hydraulics
Hydraulic system22.7 LReference
Capacity22.7 LReference
Rear PTO Type540Reference
Dimensions
Wheelbase231 cmReference
Weight2165 kgReference
Front tire6.00x20Reference
Rear tire9.00x36Reference
Ag front6.00x20Reference
Ag rear9.00x36Reference
Length370 cmReference
Width218 cmReference
Height221 cmReference
HV Serial Number Location
Serial number plate on the left side of the transmission housing.Reference
HV Serial Numbers
1939501Reference
194010653Reference
194152387Reference
194293237Reference
1943122091Reference
1944150251Reference
1945186123Reference
1946214820Reference
1947241143Reference
1948268991Reference
1949300876Reference
1950327975Reference
1951351923Reference
1952375861Reference
1953390500Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
