Tractor · Unverified
Farmall Regular
Farmall Regular — Row-Crop tractor · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Max power
9.9 kW
Weight
1814 kg
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Row-Crop tractorReference
FactoriesChicago, Illinois, USAReference
FactoriesRock Island, Illinois, USAReference
Total built134,650Reference
Two-wheel driveReference
Steeringmanual with automatic engagement of turning brakesReference
Open operator's seatReference
Engine
International Harvester 3.6L 4-cyl gasolineReference
Fuel tank49.2 LReference
Aux. fuel3.3 LReference
Plows2Reference
Drawbar (tested)9.9 kWReference
Belt (tested)15.0 kWReference
International HarvesterReference
gasolineReference
4-cylinderReference
liquid-cooled verticalReference
Displacement3.6 LReference
Bore/Stroke95 x 127 mmReference
Air cleaneroil bath and fiberReference
Rated RPM1200Reference
Starter typehand crankReference
Coolant capacity34.1 LReference
Belt power (max)15.0 kWReference
Max power9.9 kWReference
Transmission
3-speedReference
Gears3 forward and 1 reverseReference
PTO & Hydraulics
Rear PTOtransmissionReference
Rear PTO Type535Reference
Dimensions
Weight1814 kgReference
Front tire25x4Reference
Rear tire40x6Reference
Ag front25x4 steelReference
Ag rear40x6 steelReference
Lawn/turf front25x8 steel (Fairway)Reference
Lawn/turf rear40x16 steel (Fairway)Reference
Length345 cmReference
Width218 cmReference
Height170 cmReference
Regular Serial Numbers
Location:Tractor tool box.Reference
1924501Reference
1925701Reference
19261539Reference
19275969Reference
192815471Reference
192940370Reference
193075691Reference
1931117784Reference
1932131872Reference
Final134952Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter35 cmReference
Width16 cmReference
RPM693Reference
Test results
Gasoline 3-speed 2WDSeptember 14 - 19, 1925Link: Nebraska Tractor Test 117 fileReference
Belt fuel use (max)7.9 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1236 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
