Tractor · 1951Unverified
Farmall Super C
Farmall Super C · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Max power
15.5 kW
Weight
1406 kg
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Total built98,310Reference
Original price was $1,700 in 1954Reference
Two-wheel driveReference
Manual steeringReference
Differential mechanical disc brakesReference
Open operator station.Reference
Engine
International Harvester 2.0L 4-cyl gasolineReference
Fuel tank41.6 LReference
Drawbar (claimed)15.4 kWReference
Drawbar (tested)15.5 kWReference
Belt (tested)17.7 kWReference
International Harvester C123Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke79 x 102 mmReference
Air cleaneroil bathReference
Compression6:1Reference
Rated RPM1650Reference
Firing order1-3-4-2Reference
Starter volts6Reference
Oil capacity4.7 LReference
Coolant capacity14.2 LReference
Belt power (max)17.7 kWReference
Max power15.5 kWReference
Transmission
4-speed sliding gearReference
Typesliding gearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)17.7 kWReference
Typeopen centerReference
TypeFast HitchReference
Rear PTO Type540Reference
Dimensions
Wheelbase208 cmReference
Weight1406 kgReference
Front tire5.00-15Reference
Rear tire10-36Reference
Ag front5.00-15Reference
Ag rear10-36Reference
Length312 cmReference
Height189 cmReference
Operating weight1406 kgReference
Ballasted weight2285 kgReference
Rear tread119 to 203 cmReference
Super C Serial Number Location
Seat support frameReference
Super C Serial Numbers
1951FC100001Reference
1952FC131157Reference
1953FC159130Reference
1954FC187788Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter21 cmReference
Width15 cmReference
RPM1363Reference
Speed924.46 meters/minReference
Test results
Gasoline 4-speed 2WDMay 31 - June 9, 1951Link: Nebraska Tractor Test 458 fileReference
Belt fuel use (max)8.7 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1429 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
