Tractor · 1958Unverified
Farmall Super Cub
Farmall Super Cub. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Built in Saint Dizier, FranceReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
International Harvester 1.0L 4-cyl gasolineReference
International Harvester SFC-60Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke67 x 70 mmReference
Rated RPM2000Reference
Starter typeelectricReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Dimensions
Wheelbase176 cmReference
Front tire4.00x12Reference
Rear tire8.00x24Reference
Ag front4.00x12Reference
Ag rear8.00x24Reference
Length249 cmReference
Super Cub Serial Number Location
Serial number plate on the right side of the Super Cub frame, above the front axle.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
