Tractor · Unverified
Farmtrac 390HST
Farmtrac 390HST — Mitsubishi built · 39 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
39 hp
Weight
1401 kg
Hover a source tag to verify
Overview
DistributorFarmtracReference
ManufacturerMitsubishiReference
Built in Faridabad, IndiaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Two-post ROPS.Reference
Engine
Mitsubishi 1.8L 4-cyl dieselReference
Engine (gross)29.1 kWReference
Engine (net)26.8 kWReference
Mitsubishi S4L2Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke78 x 92 mmReference
Power (net)26.8 kWReference
Power (gross)29.1 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Rated RPM2700Reference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)24.6 kWReference
Valves2Reference
Pump flow30.7 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1349 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Weight1401 kgReference
Front tire8.3x16Reference
Rear tire12.4x24Reference
Ag front8.3x16Reference
Ag rear12.4x24Reference
Lawn/turf front25x10.5Reference
Lawn/turf rear41x14-20Reference
Industrial front10x16.5Reference
Industrial rear420/70x24Reference
Length312 cmReference
Width167 cmReference
Height223 cmReference
Farmtrac 390HST attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Charging amps50Reference
Battery CCA600Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
