Tractor · Unverified

Farmtrac 520

Name: Farmtrac 520
Brand: Farmtrac

Farmtrac 520 — Utility tractorEscorts built · 46 hp. Reference specifications; pending source verification.

The Farmtrac 520 is a tractor with an approximate power output of 46 hp, positioning it at the lower end of its class. It features a 3-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and an 8-speed gearbox. The tractor has an operating weight of between 4220 and 4760 pounds. It is suitable for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

46 hp

Weight

4220 to 4760 pounds

Catalogue coverage

Variants represented

Richest spec table

44 rows

Recorded power

46 hp

Recorded weight

1914 kg

Transmissions

8-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorFarmtracReference

ManufacturerEscortsReference

Utility tractorReference

Built in Faridabad, IndiaReference

Two- or four-wheel driveReference

Two-post ROPS.Reference

Engine

2.8L 3-cyl dieselReference

Engine38.8 kWReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.8 LReference

Power38.8 kWReference

Starter volts12Reference

Transmission

8-speedReference

Transmissionshuttle, partial synchromeshReference

Gears8 forward and reverseReference

PTO & Hydraulics

PTO (claimed)34.3 kWReference

Pump flow34.1 lpmReference

Rear TypeII/IReference

Rear lift1199 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Dimensions

Weight4220 to 4760 poundsReference

Front tire7.5-16Reference

Rear tire14.9-28Reference

2WD Ag front7.5-16Reference

4WD Ag front8.3-24Reference

Ag rear14.9-28Reference

Ag rear16.9-28Reference

Lawn/turf front9.5L-15Reference

Lawn/turf rear16.9-24Reference

Industrial front11L-14Reference

Industrial rear14.9-24Reference

Length347 cmReference

Width177 cmReference

Height241 cmReference

2WD Weight1914 kgReference

4WD Weight2159 kgReference

Farmtrac 520 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging amps36Reference

Battery CCA600Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
