Tractor · 2006Unverified

Farmtrac 545

Name: Farmtrac 545
Brand: Farmtrac

Farmtrac 545 — 5 Series · 37 hp. Reference specifications; pending source verification.

The Farmtrac 545 is a compact tractor model with a rated output of 37 hp. It was manufactured from 2006 to 2008 and features a 3-cylinder diesel engine. The tractor is equipped with four-wheel drive and an 8-speed gearbox, and its listed weight ranges from 4160 to 4600 pounds. Its intended application is for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

37 hp

Weight

4160 to 4600 pounds

Catalogue coverage

Variants represented

Richest spec table

43 rows

Recorded power

37 hp

Recorded weight

1886 kg

Transmissions

8-speed constant mesh

Production years

2006-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFarmtracReference

Utility tractorReference

Built in Faridabad, IndiaReference

Two- or four-wheel driveReference

Variants

545DTC4WDReference

Engine

2.9L 3-cyl dieselReference

Engine31.3 kWReference

dieselReference

3-cylinderReference

Displacement2.9 LReference

Power31.3 kWReference

Starter volts12Reference

Transmission

8-speed constant meshReference

Typeconstant meshReference

Gears8 forward and 2 reverseReference

PTO & Hydraulics

PTO (claimed)27.6 kWReference

Pump flow34.1 lpmReference

Rear TypeIReference

Rear lift1397 kgReference

Rear PTOliveReference

Rear PTO Type540Reference

Dimensions

Weight4160 to 4600 poundsReference

Front tire6.00-16Reference

Rear tire13.6-28Reference

Ag front6.00-16Reference

Ag front9.5-20 (4WD)Reference

Ag rear13.6-28Reference

Ag rear14.9-28 (4WD)Reference

Lawn/turf front24x13-12Reference

Lawn/turf rear44x18-20Reference

Industrial front11L-15Reference

Industrial rear19.5L-24Reference

Length327 cmReference

Width193 cmReference

Height215 cmReference

Weight1886 kgReference

Weight2086 kgReference

Farmtrac 545 attachments

front-end loaderReference

Electrical

Charging amps55Reference

Battery CCA800Reference

Battery volts12Reference

Attachment overview

Farmtrac 5240M loaderReference

Farmtrac 5320M loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
