Tractor · 2002Unverified
Farmtrac 675
Farmtrac 675 — Utility tractor · 67 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
67 hp
Weight
5280 to 6115 pounds
Hover a source tag to verify
Overview
DistributorFarmtracReference
ManufacturerEscortsReference
Utility tractorReference
Built in Faridabad, IndiaReference
Two- or four-wheel driveReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Two-post ROPS. Canopy optional.Reference
Variants
675DTC4WDReference
Engine
Perkins 4.4L 4-cyl dieselReference
Engine54.0 kWReference
PerkinsReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
Power54.0 kWReference
Air cleanerdual paper elementsReference
Compression19.3:1Reference
Rated RPM2200Reference
Starter volts12Reference
Power at rated engine speed50.1 kWReference
Transmission
12-speed shuttleReference
TypeshuttleReference
Gears12 forward and reverseReference
PTO & Hydraulics
PTO (tested)50.1 kWReference
Typeopen centerReference
Valves2Reference
Pump flow37.1 lpmReference
Steering flow11.4 lpmReference
Rear TypeIIReference
Rear lift (at ends)2296 kgReference
Rear lift (at 24"/610mm)1804 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Power at rated PTO speed49.7 kWReference
Dimensions
Wheelbase204 cmReference
Weight5280 to 6115 poundsReference
Front tire7.5-16Reference
Rear tire16.9-30Reference
Ag front7.5-16Reference
4WD Ag front11.2-24Reference
Ag rear16.9-30Reference
Ag rear18.4-30Reference
Length368 cmReference
Width193 cmReference
Height243 cmReference
2WD Shipping2395 kgReference
4WD Shipping2664 kgReference
4WD Operating2773 kgReference
Farmtrac 675 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging amps55Reference
Battery CCA800Reference
Battery volts12Reference
Test results
Diesel 12-speed 4WDMarch 3 - July 9, 2008Link: Nebraska Tractor Test 1917 fileReference
PTO performanceReference
Fuel use17.4 l/hourReference
Fuel use17.0 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
