Tractor · 2006Unverified
Farmtrac 7115DTC
Farmtrac 7115DTC — 7 Series · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Weight
4159 kg
Hover a source tag to verify
Overview
DistributorFarmtracReference
ManufacturerSAMEReference
Farm/Agricultural tractorReference
Built in ItalyReference
The Farmtrac 8075 was very similar to the Farmtrac 675 except for the addition of the cab.Reference
Four-wheel driveReference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Cab standard with heat and air conditioning.Reference
Engine
Deutz-Fahr 4.0L 4-cyl dieselReference
Fuel tank149.9 LReference
Engine85.0 kWReference
Deutz-FahrReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Power85.0 kWReference
Air cleanerdryReference
Starter volts12Reference
Transmission
20-speedReference
Transmissionshuttle, full synchromeshReference
Gears20 forward and reverseReference
PTO & Hydraulics
PTO (claimed)74.2 kWReference
Valves3Reference
Pump flow54.1 lpmReference
Total flow82.5 lpmReference
Steering flow28.4 lpmReference
Rear TypeIIReference
Rear lift (at ends)6201 kgReference
Rear PTOindependentReference
Rear PTO Type540/540E/1000/1000EReference
Dimensions
Weight4159 kgReference
Front tire420/70R24Reference
Rear tire480/70R34Reference
Ag front420/70R24Reference
Ag rear480/70R34Reference
Length414 cmReference
Width200 cmReference
Width251 cmReference
Height266 cmReference
Operating weight4159 kgReference
Electrical
Charging systemalternatorReference
Charging amps100Reference
Battery CCA800Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
