The Farmtrac 775DTC is a tractor with a power rating of 66 hp, positioning it centrally within its class. Manufactured from 2006 to 2008, this model features a 4-cylinder diesel liquid-cooled engine, paired with a hydrostatic transmission and four-wheel drive system. The listed weight of the Farmtrac 775DTC is 3097 kg, suitable for use on areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
66 hp
Weight
3097 kg
Catalogue coverage
Variants represented
2
Richest spec table
46 rows
Recorded power
66 hp
Recorded weight
3097 kg
Transmissions
15-speed
Production years
2006-2008
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorFarmtracReference
ManufacturerSAMEReference
Farm/Agricultural tractorReference
Built in ItalyReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
ROPSReference
Engine
Deutz-Fahr 4.0L 4-cyl dieselReference
Fuel tank65.1 LReference
Engine55.9 kWReference
Deutz-FahrReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Power55.9 kWReference
Air cleanerdryReference
Starter volts12Reference
Transmission
15-speedReference
TransmissionshuttleReference
Gears15 forward and reverseReference
PTO & Hydraulics
PTO (claimed)49.2 kWReference
Valves2Reference
Pump flow54.1 lpmReference
Total flow74.9 lpmReference
Steering flow20.8 lpmReference
Rear TypeIIReference
Rear lift (at ends)2937 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight3097 kgReference
Front tire12.4x24Reference
Rear tire16.9x30Reference
Ag front12.4x24Reference
Ag rear16.9x30Reference
Ag front13.6x24Reference
Ag rear18.4x30Reference
Length401 cmReference
Width193 cmReference
Height236 cmReference
Operating weight3097 kgReference
Electrical
Charging systemalternatorReference
Charging amps65Reference
Battery CCA800Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
