The Farmtrac 785DTC is a tractor model with a rating of approximately 75 hp, a mid-range power output for its class. Manufactured from 2006 to 2008, this model features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with a four-wheel drive and hydrostatic transmission system. It has an operating weight of 3397 kg and is designed for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
3397 kg
Catalogue coverage
Variants represented
2
Richest spec table
48 rows
Recorded power
75 hp
Recorded weight
3397 kg
Transmissions
15-speed
Production years
2006-2008
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorFarmtracReference
ManufacturerSAMEReference
Farm/Agricultural tractorReference
Built in ItalyReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
ROPSReference
Engine
Deutz-Fahr 4.0L 4-cyl dieselReference
Fuel tank80.2 LReference
Engine63.4 kWReference
Deutz-FahrReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Power63.4 kWReference
Air cleanerdryReference
Starter volts12Reference
Transmission
15-speedReference
TransmissionshuttleReference
Gears15 forward and reverseReference
PTO & Hydraulics
PTO (claimed)55.9 kWReference
Valves2Reference
Pump flow54.1 lpmReference
Total flow82.5 lpmReference
Steering flow28.4 lpmReference
Rear TypeIIReference
Rear lift (at ends)3097 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight3397 kgReference
Front tire13.6x24Reference
Rear tire18.4x30Reference
Ag front13.6x24Reference
Ag rear18.4x30Reference
Ag front12.4x24Reference
Ag front14.9x24Reference
Ag rear16.9x30Reference
Ag rear16.9x34Reference
Length401 cmReference
Width208 cmReference
Height236 cmReference
Operating weight3397 kgReference
Electrical
Charging systemalternatorReference
Charging amps65Reference
Battery CCA800Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
