Tractor · 2003Unverified
Fendt 206V
Fendt 206V — Farmer 200 Series · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Weight
4850 to 5743 pounds
Hover a source tag to verify
Overview
ManufacturerFendt (a part of AGCO)Reference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic disc brakesReference
Cab standard with available heat and air-conditioning. Two-post mid-ROPS available.Reference
Variants
206SutilityReference
206Vultra-narrowReference
206FnarrowReference
Engine
Deutz 3.2L 3-cyl dieselReference
Fuel tank70.0 LReference
Engine (gross)48.0 kWReference
Engine (net)44.0 kWReference
DeutzReference
turbocharged dieselReference
3-cylinderReference
air-cooledReference
Displacement3.2 LReference
Bore/Stroke102 x 132 mmReference
Rated Power (net)44.0 kWReference
Rated Power (gross)48.0 kWReference
Rated RPM2300Reference
Torque239.1 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speed synchromeshReference
20-speed shuttleReference
TypesynchromeshReference
Gears20 forward and 6 reverseReference
TypeshuttleReference
Gears20 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure200.0 barReference
Rear valves4Reference
Mid valves6Reference
Pump flow74.2 lpmReference
Pump flow46.9 lpmReference
Rear lift2713 kgReference
Front lift2429 kgReference
Rear PTOindependentReference
Rear PTO Type540/750/1000Reference
Rear PTO Type540/750/groundReference
Front PTOindependentReference
Front PTO Type540Reference
Front PTO Type1000Reference
Dimensions
206V Wheelbase199 cmReference
206F Wheelbase202 cmReference
Weight4850 to 5743 poundsReference
Front tire6.00-16Reference
206V 2WD Rear tire280/85R24Reference
206V 2WD Standard tires (ag)Front: 6.00-16. Rear: 280/85R24Reference
206V 4WD Standard tires (ag)Front: 7.5L15. Rear: 280/85R24Reference
206F 2WD Standard tires (ag)Front: 7.50R16. Rear: 12.4R28Reference
206F 4WD Standard tires (ag)Front: 280/70R18. Rear: 12.4R28Reference
206V Length342 cmReference
206F Length341 cmReference
206V Width106 cmReference
206F Width132 cmReference
206V Height (cab)233 cmReference
206F Height (cab)242 cmReference
206V2199 kgReference
206F2605 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Charging volts14Reference
Battery volts12Reference
Battery AH88Reference
Capacities
Max capacity3999 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
