Tractor · 2010Unverified

Fendt 209 Vario

Name: Fendt 209 Vario
Brand: Fendt

Fendt 209 Vario — Model year 2010-20172017-20192020-2025 · 90 hp. Reference specifications; pending source verification.

The Fendt 209 Vario is a tractor with a rated output of 90 hp, positioning it centrally within its class in terms of power. This model was manufactured from 2010 to 2025, and it features a 3-cylinder turbocharged diesel liquid-cooled engine. The tractor is equipped with four-wheel drive and has a listed weight of 3870 kg. It is designed for use on plots of land ranging from 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

90 hp

Max power

94 hp

Weight

3870 kg

Catalogue coverage

Variants represented

Richest spec table

99 rows

Recorded power

90 hp

Recorded weight

3870 kg

Transmissions

Vario

Production years

2010-2025

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerFendt (a part of AGCO)Reference

Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Cab standard with heater. Air-conditioning available.Reference

Engine

AGCO Power 3.3L 3-cyl dieselReference

Fuel tank124.9 LReference

Engine (gross)67.0 kWReference

Engine (net)59.0 kWReference

Engine (max)70.0 kWReference

AGCO PowerReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke108 x 120 mmReference

Rated Power (net)59.0 kWReference

Rated Power (gross)67.0 kWReference

Maximum Power (net)67.0 kWReference

Maximum Power (gross)70.0 kWReference

Rated RPM2100Reference

Torque373.0 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

Rated engine speed2,100 rpmReference

Transmission

continuously-variable transmissionReference

TransmissionVarioReference

Typecontinuously-variable transmissionReference

Gearsinfinite forward and reverseReference

Transmission TypeCVTReference

Wheel Drive4WDReference

PTO & Hydraulics

Pressure200.0 barReference

Rear valves4Reference

Mid valves2Reference

Pump flow48.1 lpmReference

Pump flow76.1 lpmReference

Controlposition and draft controlReference

Rear lift4203 kgReference

Front lift2490 kgReference

Rear PTOindependentReference

Rear PTO Type540/540E/1000Reference

Rear PTO Type540/ground/1000Reference

Engine RPM540@1900Reference

Engine RPM540E@1560Reference

Engine RPM1000@1900Reference

Front PTOindependentReference

Front PTO Type540Reference

Front PTO Type1000Reference

Dimensions

Wheelbase229 cmReference

Weight3870 kgReference

Front tire380/70R24Reference

Rear tire480/70R34Reference

Standard tires (ag)Front: 380/70R24. Rear: 480/70R34Reference

Optional tires (ag)Front: 320/70R24. Rear: 420/85R30Reference

Optional tires (ag)Front: 320/70R24. Rear: 480/70R30Reference

Optional tires (ag)Front: 440/65R24. Rear: 540/65R34Reference

Optional tires (ag)Front: 270/80R32. Rear: 270/95R44Reference

Optional tires (ag)Front: 425/75R20. Rear: 600/65R30Reference

Length406 cmReference

Width216 cmReference

Height (cab)252 cmReference

Ground clearance44 cmReference

Front tread168 cmReference

Rear tread166 cmReference

3870 kgReference

Max Drawbar1999 kgReference

Fendt 209 Vario attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps120Reference

Charging volts14Reference

Battery volts12Reference

Battery AH90Reference

Capacities

Max capacity6500 kgReference

Capacity3,300 ccReference

Diesel exhaust fluid (DEF) tank16.0 LReference

Power

Max Power94 hpReference

Rated Power91 hpReference

PTO

PTO Power68 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 rpmReference

Front PTO PowerAvailableReference

General

Cruise controltrueReference

SCV controlJoystickReference

Hydraulics

Pump Rated Output (total)75 l/minReference

Remote Valves4Reference

Number of rear selective control valves (SCVs)Option 1: 4\\nOption 2: 3Reference

Rear Hitch maximum lift capacity4,204 kgReference

Dimensions & weight

Overall Length4,119 mmReference

Overall Width2,170 mmReference

Overall weight4,220.2 kgReference

Track width1,660 mmReference

Wheels & tyres

Rear Wheel Type480/70R34Reference

Front Wheel Type380/70R24Reference

Operator station

Cab AvailabilitytrueReference

Seat SuspensiontrueReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
