Tractor · 2006Unverified
Fendt 310 Vario
Fendt 310 Vario — Model year 2006-20122012-20142014-2019 · 89 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
89 hp
Weight
8378 to 9105 pounds
Hover a source tag to verify
Overview
ManufacturerFendt (a part of AGCO)Reference
Two- or four-wheel driveReference
Power steeringReference
2WD BrakesdrumReference
4WD Brakeswet discReference
Cab standard with heat. Air-conditioning optional.Reference
Engine
Deutz 4.0L 4-cyl dieselReference
Fuel tank210.1 LReference
Engine (net)66.0 kWReference
DeutzReference
turbocharged intercooled dieselReference
4-cylinder 16-valveReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke101 x 126 mmReference
Rated Power (net)66.0 kWReference
Maximum Power (net)77.0 kWReference
Fuel systemcommon railReference
Rated RPM2100Reference
Torque445.0 NmReference
Torque RPM1450Reference
StarterelectricReference
Starter volts12Reference
Oil change500 hReference
Transmission
continuously variable transmissionReference
TransmissionVarioReference
Typecontinuously variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure200.0 barReference
Valves2 to 4Reference
Pump flow78.0 lpmReference
Rear lift5381 kgReference
Front lift2996 kgReference
Rear PTOindependentReference
Rear PTO Type540/540E/1000Reference
Front PTOindependentReference
Front PTO Type540Reference
Front PTO Type1000Reference
Dimensions
Wheelbase234 cmReference
Weight8378 to 9105 poundsReference
Front tire11.00-16Reference
2WD Rear tire540/65R34Reference
2WD Standard tires (ag)Front: 11.00-16. Rear: 540/65R34Reference
4WD Standard tires (ag)Front: 440/65R24. Rear: 540/65R34Reference
4WD Optional tires (ag)Front: 14.9R24. Rear: 600/65R34Reference
4WD Optional tires (ag)Front: 270/95R32. Rear: 270/95R48Reference
4WD Optional tires (ag)Front: 425/75R20. Rear: 600/65R30Reference
Length415 cmReference
Width227 cmReference
Height (cab)274 cmReference
Ground clearance43 cmReference
2WD Front tread157 cmReference
4WD Front tread168 cmReference
Rear tread166 cmReference
2WD Operating3800 kgReference
4WD Operating4130 kgReference
Max Drawbar1999 kgReference
Fendt 310 Vario attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps143Reference
Charging volts14Reference
Battery volts12Reference
Battery AH90Reference
Attachment overview
Fendt 3S/60 loaderReference
Fendt 3S/63 loaderReference
Capacities
2WD Max capacity6000 kgReference
4WD Max capacity7500 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
