Tractor · 2006Unverified
Fendt 818 Vario
Fendt 818 Vario · 186 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
186 hp
Weight
7021 kg
Hover a source tag to verify
Overview
ManufacturerFendtReference
Built in Marktoberdorf, GermanyReference
Four-wheel driveReference
Wet discs brakesReference
Cab standard with air-conditioning.Reference
Engine
Deutz 6.1L 6-cyl dieselReference
Fuel tank339.9 LReference
Engine (gross)138.7 kWReference
Engine (net)126.8 kWReference
Engine (max)143.2 kWReference
Deutz TCD 2012 L06 4VReference
turbocharged intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement6.1 LReference
Bore/Stroke101 x 126 mmReference
EmissionsTier IIIaReference
Emission controlegrReference
Rated Power (net)126.8 kWReference
Rated Power (gross)138.7 kWReference
Maximum Power (net)138.0 kWReference
Maximum Power (gross)143.2 kWReference
Rated RPM2100Reference
Torque802.8 NmReference
Torque RPM1450Reference
Starter power3.0 kWReference
Oil change500 hReference
Transmission
continuously variable transmission (IVT)Reference
TransmissionFendt VarioReference
Typecontinuously variable transmission (IVT)Reference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)119.3 kWReference
Typeload sensingReference
Pressure200.0 barReference
Valves3 or 4Reference
Total flow110.1 lpmReference
Rear lift6053 kgReference
Front lift2503 kgReference
Rear PTO Type540/540E/1000Reference
Front PTO Type1000 (optional)Reference
Dimensions
Wheelbase271 cmReference
Weight7021 kgReference
Length474 cmReference
Width274 cmReference
Height302 cmReference
Max weight12499 kgReference
Ground clearance55 cmReference
Front tread193 cmReference
Rear tread191 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps200Reference
Battery CCA1020Reference
Battery volts12Reference
Battery AH170Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
