Tractor · 1964Unverified

Fendt F230GT

Name: Fendt F230GT
Brand: Fendt

Fendt F230GT · 30 hp. Reference specifications; pending source verification.

The Fendt F230GT is a tractor with a rated power output of 30 hp, positioned at the lower end of its class in terms of power. It was manufactured between the years of 1964 and 1967. The F230GT is equipped with a 3-cylinder diesel engine, coupled to an 8-speed gearbox. Its operating weight is specified at 1500 kg, allowing it to be used for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Weight

1500 kg

Catalogue coverage

Variants represented

Richest spec table

21 rows

Recorded power

30 hp

Recorded weight

1500 kg

Transmissions

8-speed

Production years

1964-1967

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerFendtReference

Engine

MWM 2.2L 3-cyl dieselReference

Fuel tank0.0 LReference

Engine22.4 kWReference

MWMReference

dieselReference

3-cylinderReference

Displacement2.2 LReference

Bore/Stroke95 x 105 mmReference

Power22.4 kWReference

Rated RPM2000Reference

Transmission

8-speedReference

Gears8 forward and 4 reverseReference

Dimensions

Wheelbase241 cmReference

Weight1500 kgReference

Front tire5.50-16Reference

Rear tire9-30Reference

Ag front5.50-16Reference

Ag rear9-30Reference

Length365 cmReference

Height162 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
