Tractor · 1976Unverified
Fendt F275GT
Fendt F275GT — Tool Carrier tractor · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
3719 kg
Hover a source tag to verify
Overview
ManufacturerFendtReference
Tool Carrier tractorReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic brakesReference
Cab standardReference
Engine
KHD 3.8L 4-cyl dieselReference
Fuel tank79.9 LReference
Engine52.2 kWReference
KHD F4L915HReference
dieselReference
4-cylinderReference
air-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power52.2 kWReference
Fuel systemdirect injectionReference
Rated RPM2300Reference
Torque245.0 NmReference
Torque RPM1600Reference
Starter volts12Reference
Transmission
14-speed synchromeshReference
20-speed creeperReference
TypesynchromeshReference
Gears14 forward and 4 reverseReference
Clutchmechanical dry discReference
TypecreeperReference
Gears20 forward and 6 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure175.0 barReference
Pump flow40.1 lpmReference
Rear lift2721 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase312 cmReference
Weight3719 kgReference
Front tire7.50-16Reference
Rear tire13.6-38Reference
Ag front7.50-16Reference
Ag rear13.6-38Reference
Length477 cmReference
Width187 cmReference
Height (cab)259 cmReference
Ground clearance48 cmReference
Front tread135/150/164/169/180 cmReference
Rear tread150/164 cmReference
Electrical
Charging systemalternatorReference
Charging amps33Reference
Charging volts14Reference
Battery volts12Reference
Battery AH110Reference
Speeds
With 16.9/14-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
