The Fendt F390GH tractor is a mid-range model rated at approximately 100 hp. It was manufactured from 1985 to 1989. The model features a 6-cylinder diesel engine and four-wheel drive, paired with a 21-speed gearbox. Its operating weight is listed at 4885 kg, suitable for operations spanning 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Weight
4885 kg
Catalogue coverage
Variants represented
2
Richest spec table
27 rows
Recorded power
100 hp
Recorded weight
4885 kg
Transmissions
21-speed
Production years
1985-1989
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerFendtReference
Four-wheel driveReference
Engine
KHD 6.1L 6-cyl dieselReference
Fuel tank160.1 LReference
Engine74.6 kWReference
KHDReference
dieselReference
6-cylinderReference
Displacement6.1 LReference
Bore/Stroke102 x 125 mmReference
Power74.6 kWReference
Rated RPM2300Reference
Torque369.1 NmReference
Torque RPM1600Reference
Transmission
21-speedReference
Gears21 forward and 6 reverseReference
PTO & Hydraulics
Pump flow71.2 lpmReference
Rear lift5150 kgReference
Rear PTO Type540, 750, 1000Reference
Dimensions
Wheelbase292 cmReference
Weight4885 kgReference
Front tire16.9R34Reference
Rear tire18.4R38Reference
Ag front16.9R34Reference
Ag rear18.4R38Reference
Length481 cmReference
Height299 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
