Tractor · 1985Unverified
Fendt F390GT
Fendt F390GT · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Weight
4775 kg
Hover a source tag to verify
Overview
ManufacturerFendtReference
Four-wheel driveReference
Engine
KHD 6.1L 6-cyl dieselReference
Fuel tank160.1 LReference
Engine74.6 kWReference
KHDReference
dieselReference
6-cylinderReference
Displacement6.1 LReference
Bore/Stroke102 x 125 mmReference
Power74.6 kWReference
Rated RPM2300Reference
Torque369.1 NmReference
Torque RPM1600Reference
Transmission
21-speedReference
Gears21 forward and 6 reverseReference
PTO & Hydraulics
Pump flow71.2 lpmReference
Rear lift5150 kgReference
Rear PTO Type540, 750, 1000Reference
Dimensions
Wheelbase276 cmReference
Weight4775 kgReference
Front tire14.9R28Reference
Rear tire18.4R38Reference
Ag front14.9R28Reference
Ag rear18.4R38Reference
Length472 cmReference
Height269 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
