Tractor · 1987Unverified
Fendt Farmer 250S
Fendt Farmer 250S — Farmer 200 Series · 49 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
5512 to 6063 pounds
Hover a source tag to verify
Overview
ManufacturerFendtReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic drum brakesReference
Cab standard with heat. Air-conditioning optional.Reference
Variants
250S2WDReference
Engine
KHD 2.8L 3-cyl dieselReference
Fuel tank60.2 LReference
Engine36.8 kWReference
KHD F3L912Reference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.8 LReference
Bore/Stroke100 x 120 mmReference
Power36.8 kWReference
Fuel systemdirect injectionReference
Rated RPM2300Reference
Torque176.0 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Transmission
21-speedReference
21-speed shuttleReference
Gears21 forward and 6 reverseReference
Gearshift with three gears (1-3), plus reverse (R), and three overdrive gears (25, 30, and 40 kph). Triple range gear split provides three speeds for each of the non-overdrive gears. Low and high ranges. Transmission also available with addition super-creeper range providing 30 gears forward and 9 reverse.Reference
TypeshuttleReference
Gears21 forward and reverseReference
PTO & Hydraulics
Pressure180.0 barReference
Pump flow39.0 lpmReference
Rear lift2790 kgReference
Rear PTOindependentReference
Rear PTO Type540/750/1000Reference
Front PTO Type1000Reference
Dimensions
Wheelbase204 cmReference
Weight5512 to 6063 poundsReference
Front tire7.50-18Reference
2WD Rear tire14.9R30Reference
2WD Standard tires (ag)Front: 7.50-18. Rear: 14.9R30Reference
4WD Standard tires (ag)Front: 11.2R20. Rear: 14.9R30Reference
Length353 cmReference
Width187 cmReference
Height (cab)230 cmReference
2WD Ground clearance37 cmReference
4WD Ground clearance33 cmReference
2WD Front tread148 cmReference
4WD Front tread150 cmReference
Rear tread150 cmReference
Rear tread128 to 178 cmReference
2WD2500 kgReference
4WD2750 kgReference
Max Drawbar1000 kgReference
Fendt Farmer 250S attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Charging volts14Reference
Battery volts12Reference
Battery AH88Reference
Capacities
2WD Max capacity4500 kgReference
4WD Max capacity5000 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
