Tractor · 1987Unverified
Fendt Farmer 270V
Fendt Farmer 270V — Farmer 200 Series · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
5004 to 5159 pounds
Hover a source tag to verify
Overview
ManufacturerFendtReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Power steeringReference
Mechanical drum brakesReference
Two-post mid-mount folding ROPS. Cab available with heat and air-conditioning.Reference
Engine
KHD 3.8L 4-cyl dieselReference
Fuel tank60.0 LReference
Engine52.0 kWReference
KHD F4L912Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power52.0 kWReference
Rated RPM2300Reference
Torque251.0 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speedReference
Gears20 forward and 6 reverseReference
Gears20 forward and reverseReference
PTO & Hydraulics
Pressure180.0 barReference
Total flow46.9 lpmReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Rear PTO Type540/750/1000Reference
Dimensions
2WD Wheelbase210 cmReference
4WD Wheelbase209 cmReference
Weight5004 to 5159 poundsReference
Front tire10.0/75-15.3Reference
Rear tire9.5-28Reference
Standard tires (ag)Front: 10.0/75-15.3. Rear: 9.5-28Reference
Wide Standard tires (ag)Front: 11LR16. Rear: 13.6R24Reference
Tall Standard tires (ag)Front: 275/80R18. Rear: 13.6-28Reference
Length344 cmReference
Width117 cmReference
Wide Width124 cmReference
Tall Width130 cmReference
2WD Ground clearance29 cmReference
4WD Ground clearance22 cmReference
Wide Ground clearance25 cmReference
Tall Ground clearance28 cmReference
2WD Front tread76 cmReference
4WD Front tread79 cmReference
Wide Front tread95 cmReference
Tall Front tread96 cmReference
Rear tread85 cmReference
Wide Rear tread89 cmReference
Tall Rear tread95 cmReference
2269 kgReference
Wide2300 kgReference
Tall2340 kgReference
Max Drawbar1000 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Charging volts14Reference
Battery volts12Reference
Battery AH88Reference
Capacities
Max capacity3499 kgReference
Fendt Farmer 270V Height
ROPS221 cmReference
Wide ROPS224 cmReference
Tall ROPS226 cmReference
Cab217 cmReference
Wide/Tall Cab219 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
