Tractor · 1987Unverified
Fendt Farmer 280P
Fendt Farmer 280P — Farmer 200 Series · 79 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
79 hp
Weight
2770 kg
Hover a source tag to verify
Overview
ManufacturerFendtReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic drum brakesReference
Two-post mid-mount folding ROPS. Cab available with heat and air-conditioning.Reference
Engine
KHD 4.1L 4-cyl dieselReference
Fuel tank60.0 LReference
Engine59.0 kWReference
KHD F4L913Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.1 LReference
Bore/Stroke102 x 125 mmReference
Power59.0 kWReference
Rated RPM2400Reference
Torque272.0 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
21-speedReference
Gears21 forward and 6 reverseReference
Gears21 forward and reverseReference
PTO & Hydraulics
Pressure180.0 barReference
Total flow68.9 lpmReference
Rear PTOindependentReference
Rear PTO Type540/750Reference
Rear PTO Type540/750/1000Reference
Dimensions
Wheelbase217 cmReference
Weight2770 kgReference
Front tire275/70-18Reference
Rear tire14.9-28Reference
Standard tires (ag)Front: 275/70-18. Rear: 14.9-28Reference
Length366 cmReference
Width166 cmReference
Height (ROPS)224 cmReference
Height (cab)226 cmReference
2WD Ground clearance35 cmReference
4WD Ground clearance25 cmReference
2WD Front tread123 cmReference
4WD Front tread121 cmReference
Wide Front tread149 cmReference
Rear tread128 cmReference
Wide Rear tread148 cmReference
2770 kgReference
Max Drawbar1000 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Charging volts14Reference
Battery volts12Reference
Battery AH88Reference
Capacities
2WD Max capacity3999 kgReference
4WD Max capacity5000 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
