Tractor · 1996Unverified
Fendt Farmer 280S
Fendt Farmer 280S — Farmer 200 Series · 79 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
79 hp
Weight
2970 kg
Hover a source tag to verify
Overview
ManufacturerFendtReference
Row-Crop tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic drum brakesReference
Cab standard with heat. Air-conditioning optional.Reference
Engine
KHD 4.1L 4-cyl dieselReference
Fuel tank60.2 LReference
Engine59.0 kWReference
KHD F4L913Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.1 LReference
Bore/Stroke102 x 125 mmReference
Power59.0 kWReference
Fuel systemdirect injectionReference
Rated RPM2300Reference
Torque272.0 NmReference
Torque RPM1550Reference
StarterelectricReference
Starter volts12Reference
Transmission
21-speedReference
21-speed shuttleReference
Gears21 forward and 6 reverseReference
Gearshift with three gears (1-3), plus reverse (R), and three overdrive gears (25, 30, and 40 kph). Triple range gear split provides three speeds for each of the non-overdrive gears. Low and high ranges. Transmission also available with addition super-creeper range providing 30 gears forward and 9 reverse.Reference
TypeshuttleReference
Gears21 forward and reverseReference
PTO & Hydraulics
Pressure180.0 barReference
Pump flow40.9 lpmReference
Rear lift2790 kgReference
Rear PTOindependentReference
Rear PTO Type540/750/1000Reference
Front PTO Type1000Reference
Dimensions
Wheelbase217 cmReference
Weight2970 kgReference
Front tire12.4R20Reference
Rear tire16.9R30Reference
Standard tires (ag)Front: 12.4R20. Rear: 16.9R30Reference
Length363 cmReference
Width187 cmReference
Height (cab)234 cmReference
Ground clearance33 cmReference
Front tread150 cmReference
Rear tread150 cmReference
Rear tread128 to 178 cmReference
2970 kgReference
Max Drawbar1000 kgReference
Fendt Farmer 280S attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Charging volts14Reference
Battery volts12Reference
Battery AH88Reference
Capacities
Max capacity5000 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
