Tractor · 1993Unverified

Fendt Farmer 308

Name: Fendt Farmer 308
Brand: Fendt

Fendt Farmer 308 — Farmer 300 Series · 96 hp. Reference specifications; pending source verification.

The Fendt Farmer 308 is a tractor model with a rated power output of 96 hp, a mid-range figure for its class. It was manufactured between 1993 and 2000. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine paired with four-wheel drive and a powershift transmission. Its operating weight is 4160 kg, making it suitable for operations on areas ranging from 200 to 800 ac.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

96 hp

Weight

4160 kg

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

96 hp

Recorded weight

4160 kg

Transmissions

21-speed three-speed power shift

Production years

1993-2000

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerFendtReference

Row-Crop tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic disc brakesReference

Cab standard with air-conditioning.Reference

Engine

MWM 4.2L 4-cyl dieselReference

Fuel tank107.1 LReference

Engine71.6 kWReference

MWM TD226.B4Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.2 LReference

Bore/Stroke105 x 120 mmReference

Power71.6 kWReference

Rated RPM2250Reference

Torque353.1 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Transmission

21-speed three-speed power shiftReference

Typethree-speed power shiftReference

Gears21 forward and reverseReference

Three gears, in two ranges, with a three-speed power shift. Additional three overdrive gear ranges. The 40 kph overdrive was not available in all markets.Reference

PTO & Hydraulics

Pump flow74.9 lpmReference

Rear lift4488 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/750/1000Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase228 cmReference

Weight4160 kgReference

Front tire380/70R24Reference

Rear tire480/70R34Reference

Standard tires (ag)Front: 380/70R24. Rear: 480/70R34Reference

Optional tires (ag)Front: 13.6-24. Rear: 13.6R38Reference

Optional tires (ag)Front: 13.6-24. Rear: 14.9R38Reference

Optional tires (ag)Front: 14.9R24. Rear: 18.4R34Reference

Optional tires (ag)Front: 420/70R24. Rear: 520/70R34Reference

Optional tires (ag)Front: 420/70R24. Rear: 480/70R38Reference

Optional tires (ag)Front: 460/70R24. Rear: 540/70R34Reference

Optional tires (ag)Front: 480/65R24. Rear: 600/65R34Reference

Optional tires (ag)Front: 11.2R28. Rear: 11.2R44Reference

Optional tires (ag)Front: 9.5R32. Rear: 9.5R48Reference

Length404 cmReference

Width214 cmReference

Height (cab)266 cmReference

Max weight7500 kgReference

Front tread170 cmReference

Rear tread166 cmReference

Fendt Farmer 308 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps95Reference

Battery volts12Reference

Battery AH110Reference

Attachment overview

Fendt 3/60 loaderReference

Fendt 3S loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
