Tractor · 1970Unverified

Fendt Favorit 10S

Name: Fendt Favorit 10S
Brand: Fendt

Fendt Favorit 10S · 90 hp. Reference specifications; pending source verification.

The Fendt Favorit 10S is a tractor model with a rated power output of 90 hp, which falls within the mid-range for its class. Manufactured between 1970 and 1972, this model features a 6-cylinder diesel liquid-cooled engine and a four-wheel drive system paired with a 16-speed gearbox. Its operating weight is listed as 8587 to 8940 pounds. Suitable for operations spanning 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

90 hp

Weight

8587 to 8940 pounds

Catalogue coverage

Variants represented

Richest spec table

40 rows

Recorded power

90 hp

Recorded weight

3895 kg

Transmissions

16-speed

Production years

1970-1972

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerFendtReference

Built in Marktoberdorf, GermanyReference

Two- or four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Open operator station.Reference

Engine

MWM 5.1L 6-cyl dieselReference

Fuel tank129.8 LReference

Engine (gross)67.1 kWReference

Engine (net)59.7 kWReference

MWM D225Reference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement5.1 LReference

Bore/Stroke95 x 120 mmReference

Power (net)59.7 kWReference

Power (gross)67.1 kWReference

Rated RPM2200Reference

Starter volts12Reference

Transmission

16-speedReference

20-speed creeperReference

Gears16 forward and 8 reverseReference

TypecreeperReference

Gears20 forward and 10 reverseReference

PTO & Hydraulics

Rear lift3000 kgReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase261 cmReference

Weight8587 to 8940 poundsReference

Front tire7.50-20Reference

2WD Rear tire14-34Reference

2WD Standard tires (ag)Front: 7.50-20. Rear: 14-34Reference

4WD Standard tires (ag)Front: 9-24. Rear: 14-34Reference

Length439 cmReference

Width210 cmReference

Height (steering wheel)193 cmReference

Height (ROPS)254 cmReference

2WD Weight3895 kgReference

4WD Weight4055 kgReference

Ground clearance40 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
