The Fendt Fix 16 is a tractor with a rated power of 16 hp, categorising it amongst the lighter models within its class. It was manufactured from 1961 to 1963. The tractor features a 2-cylinder diesel engine, paired with two-wheel drive and a 6-speed gearbox. Its operating weight is listed at 1265 kg, making it suitable for operations up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
1265 kg
Catalogue coverage
Variants represented
2
Richest spec table
28 rows
Recorded power
16 hp
Recorded weight
1265 kg
Transmissions
6-speed gear
Production years
1961-1963
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerFendtReference
Utility tractorReference
Total built963Reference
Two-wheel driveReference
Open operator station.Reference
Engine
MWM 1.3L 2-cyl dieselReference
Engine11.9 kWReference
MWM KD211ZReference
dieselReference
2-cylinderReference
Displacement1.3 LReference
Bore/Stroke85 x 110 mmReference
Power11.9 kWReference
Rated RPM2000Reference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Weight1265 kgReference
Front tire5.00-16Reference
Rear tire8-28Reference
Ag front5.00-16Reference
Ag rear8-28Reference
Ag rear10-24Reference
Length289 cmReference
Width151 cmReference
Height (steering wheel)143 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
