The Fendt Fix 2 FW120 is a tractor with a rated engine power of approximately 18 hp, categorising it within the lighter end of its class. Manufactured from 1959 to 1964, this model features a 2-cylinder diesel liquid-cooled engine and a two-wheel drive system with a 6-speed gearbox. The Fix 2 FW120 has a listed operating weight of 1364 kg and is suitable for operations on up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
1364 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
18 hp
Recorded weight
1364 kg
Transmissions
6-speed gear
Production years
1959-1964
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerFendtReference
Total built2292Reference
Two-wheel driveReference
Open operator station.Reference
Variants
FL120air-cooledReference
FW120liquid-cooledReference
Engine
MWM 1.3L 2-cyl dieselReference
Fuel tank29.9 LReference
Engine13.4 kWReference
MWM KD 211 ZReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke85 x 110 mmReference
Power13.4 kWReference
Compression18:1Reference
Rated RPM2000Reference
Starter volts12Reference
Coolant capacity7.0 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Pump flow11.0 lpmReference
Rear PTO Type540Reference
Dimensions
Wheelbase175 cmReference
Weight1364 kgReference
Front tire5.00-16Reference
Rear tire9.5-28Reference
Ag front5.00-16Reference
Ag rear9.5-28Reference
Length289 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
