The Fendt Fix 2D is a compact tractor model with a rated output of 17 hp, featuring a 2-cylinder diesel air-cooled engine. It was produced from 1963 to 1967 and is equipped with two-wheel drive and a 6-speed gearbox. The tractor's listed weight is 1265 kg, making it suitable for jobs covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
1265 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
17 hp
Recorded weight
1265 kg
Transmissions
6-speed gear
Production years
1963-1967
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerFendtReference
Utility tractorReference
Total built2507Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
MWM 1.4L 2-cyl dieselReference
Engine12.7 kWReference
MWM AKD311ZReference
dieselReference
2-cylinderReference
air-cooledReference
Displacement1.4 LReference
Bore/Stroke90 x 110 mmReference
Power12.7 kWReference
Compression19:1Reference
Rated RPM2000Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase175 cmReference
Weight1265 kgReference
Front tire5.00-16Reference
Rear tire8-28Reference
Ag front5.00-16Reference
Ag rear8-28Reference
Ag rear10-24Reference
Length289 cmReference
Width151 cmReference
Height143 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
