The Fendt Xylon 520 is a tractor model with a rated output of 110 hp, positioning it towards the middle of its class in terms of power. It was manufactured between 1995 and 2004. The Xylon 520 features a 4-cylinder turbocharged diesel liquid-cooled engine, which drives the four-wheel drive via a 44-speed gearbox. Its listed weight is 6175 kg, suitable for tasks covering approximately 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
110 hp
Weight
6175 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
110 hp
Recorded weight
6175 kg
Transmissions
44-speed
Production years
1995-2004
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerFendtReference
Tool Carrier tractorReference
Drive4x4 4WDReference
Engine
MAN 4.6L 4-cyl dieselReference
Fuel tank230.1 LReference
Engine82.0 kWReference
MANReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.6 LReference
Bore/Stroke108 x 125 mmReference
Power82.0 kWReference
Rated RPM2300Reference
Torque437.0 NmReference
Torque RPM1400Reference
Transmission
44-speedReference
Gears44 forward and reverseReference
PTO & Hydraulics
Pump flow101.8 lpmReference
Rear lift6045 kgReference
Rear PTO Type540, 750, 1000, 1400Reference
Dimensions
Wheelbase310 cmReference
Weight6175 kgReference
Front tire480/70R28Reference
Rear tire480/70R38Reference
Ag front480/70R28Reference
Ag rear480/70R38Reference
Length542 cmReference
Height302 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
