The Ferguson A is a tractor model with a rated power of 20 hp, positioned at the lower end of its class in terms of power output. The Ferguson A was manufactured between 1936 and 1937. This model features a 4-cylinder petrol liquid-cooled engine and two-wheel drive with a 3-speed gearbox, suitable for operations up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Catalogue coverage
Variants represented
2
Richest spec table
25 rows
Recorded power
20 hp
Transmissions
3-speed gear
Production years
1936-1937
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorFergusonReference
ManufacturerDavid BrownReference
Utility tractorReference
Original price200 GBP (1938)Reference
The Ferguson-Brown Type A tractor was the first production tractor with the Ferguson three-point system, following the success of the "Black Tractor".Reference
Two-wheel driveReference
SteeringmanualReference
Drum brakesReference
Open operator station.Reference
Engine
Coventry-Climax 4-cyl gasolineReference
David Brown 2.0L 4-cyl gasolineReference
Engine14.9 kWReference
Plows2 (10-inch)Reference
Coventry-Climax EReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Power14.9 kWReference
Rated RPM1400Reference
David BrownReference
Displacement2.0 LReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
A Serial Number Location
Serial number plate on the dashboard of the Ferguson A, to the left of the steering column.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
