Tractor · 1984Unverified
Fiat 140-90
Fiat 140-90 — 90 Series · 140 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
140 hp
Weight
6471 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockhydrostatic front and rearReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard with heat. Air-conditioning optional.Reference
Variants
140-902WDReference
140-90DT4WDReference
Engine
Fiat 5.9L 6-cyl dieselReference
Engine104.4 kWReference
Fiat 8065.25Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke104 x 115 mmReference
Power104.4 kWReference
Rated RPM2500Reference
Oil capacity15.2 LReference
Transmission
24-speed synchronizedReference
16-speed mechanical shuttleReference
24-speed partial power shiftReference
TypesynchronizedReference
Gears24 forward and 8 reverseReference
Clutchhydraulic 356mm cerametallic dry discReference
Four gears (1-4) in three forward ranges (low, medium, high) plus reverse range. Additional creeper mode doubles available ranges.Reference
Typemechanical shuttleReference
Gears16 forward and reverseReference
Four gears in four ranges with mechanical reverser.Reference
Typepartial power shiftReference
Four power-shift gears (1-4) in three forward ranges (low, medium, high) plus reverse range. Additional creeper mode doubles available ranges.Reference
Four power-shift gears in four ranges with mechanical reverser.Reference
Capacities
Fuel180.2 LReference
PTO & Hydraulics
Hydraulic system44.7 LReference
Hydraulic system46.2 LReference
Capacity44.7 LReference
Capacity46.2 LReference
Pressure171.6 barReference
Valves1 to 3Reference
Pump flow58.3 lpmReference
Rear Type2Reference
Controlposition and draft controlReference
Rear lift (at ends)6649 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000Reference
Front PTOindependentReference
Clutchelectro-magneticReference
Front PTO Type1000Reference
Dimensions
Wheelbase267 cmReference
Weight6471 kgReference
Front tire9.00-16Reference
Rear tire20.8-38Reference
Ag front9.00-16 (2WD)Reference
Ag front10.00-16 (2WD)Reference
Ag front11.00-16 (2WD)Reference
Ag front18.4R70-28 (4WD)Reference
Ag rear20.8-38Reference
Length418 cmReference
Height289 cmReference
Electrical
GroundnegativeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
