Tractor · 1959Unverified
Fiat 211R Vinedo
Fiat 211R Vinedo — 200 Series · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Weight
899 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Orchard/Vineyard tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
Normalutility chassisReference
Frutallow-profileReference
Vinedonarrow-profileReference
Engine
FIAT 1.1L 2-cyl dieselReference
Engine15.8 kWReference
Drawbar (claimed)13.7 kWReference
Belt (claimed)14.4 kWReference
FIATReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke85 x 100 mmReference
Power15.8 kWReference
Compression21.5:1Reference
Rated RPM2300Reference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540Reference
Engine RPM540@2120Reference
Dimensions
Wheelbase151 cmReference
Weight899 kgReference
Length246 cmReference
Width100 cmReference
Height (steering wheel)131 cmReference
Clearance (front axle)32 cmReference
Front tread88 to 128 cmReference
Rear tread78 to 129 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
