Tractor · 1959Unverified
Fiat 221R
Fiat 221R — 200 Series · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Weight
907 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Two-wheel driveReference
Engine
FIAT 1.1L 2-cyl dieselReference
Engine15.7 kWReference
Drawbar (claimed)13.7 kWReference
Belt (claimed)14.4 kWReference
FIATReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke85 x 100 mmReference
Power15.7 kWReference
Compression21.5:1Reference
Rated RPM2300Reference
Starter volts12Reference
Transmission
6-speedReference
Transmissionsliding gearReference
Gears6 forward and 2 reverseReference
Dimensions
Weight907 kgReference
Front tire4.00-15Reference
Rear tire9-24Reference
Ag front4.00-15Reference
Ag rear9-24Reference
Length259 cmReference
Width120 cmReference
Width191 cmReference
Height129 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
