Tractor · 1971Unverified
Fiat 300
Fiat 300 — Utility tractor · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
2358 to 2688 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Two- or four-wheel driveReference
Final drivesspur gearReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Variants
3002WDReference
300DT4WDReference
300FnarrowReference
300MMountainReference
Engine
Fiat 1.6L 2-cyl dieselReference
Fuel tank28.8 LReference
Engine20.9 kWReference
Fiat 8025.02Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke95 x 110 mmReference
Power20.9 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2400Reference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutch215.9mm dry discReference
PTO & Hydraulics
Typeopen centerReference
Pressure147.0 barReference
Pump flow9.8 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)749 kgReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2120Reference
Engine RPM994@2250Reference
Dimensions
2WD Wheelbase169 cmReference
4WD Wheelbase172 cmReference
300F Wheelbase152 cmReference
Weight2358 to 2688 poundsReference
Front tire5.00-15Reference
2WD Rear tire11.2/10-24Reference
2WD Standard tires (ag)Front: 5.00-15. Rear: 11.2/10-24Reference
4WD Standard tires (ag)Front: 9.5/9-24. Rear: 8.00-20Reference
300F Standard tires (ag)Front: 5.00-15. Rear: 9.5/9-24Reference
2WD Length274 cmReference
4WD Length271 cmReference
300F Length263 cmReference
Width130 cmReference
2WD Clearance (front axle)52 cmReference
4WD Clearance (front axle)33 cmReference
2WD Front tread104 to 164 cmReference
4WD Front tread129 cmReference
Rear tread99 to 169 cmReference
2WD1069 kgReference
4WD1219 kgReference
300F1147 kgReference
2WD Steering wheel156 cmReference
4WD Steering wheel153 cmReference
300F Steering wheel136 cmReference
300 Serial Numbers
Location:Serial number plate on the left side of the chassis.Reference
Capacities
Diameter20 cmReference
Width11 cmReference
RPM1431Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH88Reference
Fiat 300 Height
2WD Hood133 cmReference
4WD Hood131 cmReference
300F Hood115 cmReference
ROPS231 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
