Tractor · 1971Unverified
Fiat 300M
Fiat 300M — Four-wheel Drive (4WD) tractor · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1269 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Variants
3002WDReference
300DT4WDReference
300FnarrowReference
300MMountainReference
Engine
Fiat 1.6L 2-cyl dieselReference
Fuel tank28.8 LReference
Engine20.9 kWReference
Fiat 8025.02Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke95 x 110 mmReference
Power20.9 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2400Reference
Starter volts12Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutch215.9mm dry discReference
PTO & Hydraulics
Typeopen centerReference
Pressure147.0 barReference
Pump flow9.8 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)749 kgReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2120Reference
Engine RPM994@2250Reference
Dimensions
Wheelbase141 cmReference
Weight1269 kgReference
Front tire8.00-20Reference
Rear tire8.00-20Reference
Standard tires (ag)Front: 8.00-20. Rear: 8.00-20Reference
Optional tires (ag)Front: 9.5/9-24. Rear: 9.5/9-24Reference
Length295 cmReference
Height (steering wheel)148 cmReference
Height (hood)135 cmReference
Clearance (front axle)41 cmReference
Front tread119/139 cmReference
Rear tread119/139 cmReference
300M Serial Numbers
Location:Serial number plate on the left side of the chassis.Reference
Capacities
Diameter20 cmReference
Width11 cmReference
RPM1431Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH77Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
