The Fiat 315 is a compact tractor model, rated at 33 hp. It was produced from 1965 to 1968. The 4-cylinder diesel engine, which is liquid-cooled, powers the tractor through a 6-speed gearbox and four-wheel drive system. Its weight range is between 3329 and 4233 pounds, suitable for tasks covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
3329 to 4233 pounds
Catalogue coverage
Variants represented
2
Richest spec table
43 rows
Recorded power
33 hp
Recorded weight
1510 kg
Transmissions
6-speed gear
Production years
1965-1968
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Built in Modena, ItalyReference
Two- or four-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Fiat 1.9L 4-cyl dieselReference
Fuel tank49.2 LReference
Engine24.6 kWReference
Fiat 605D015Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Bore/Stroke82 x 90 mmReference
Power24.6 kWReference
Compression22.5:1Reference
Rated RPM2500Reference
Starter typeelectricReference
Transmission
6-speed gearReference
9-speed creeperReference
TypegearReference
Gears6 forward and 2 reverseReference
Three gears, plus reverse, in two ranges.Reference
TypecreeperReference
Gears9 forward and 3 reverseReference
Optional creeper adds an additional low range to the base transmission.Reference
PTO & Hydraulics
Typeopen centerReference
Pump flow21.2 lpmReference
Rear TypeIReference
Rear lift1200 kgReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase193 cmReference
Weight3329 to 4233 poundsReference
Front tire6.00-16Reference
Rear tire12.4-28Reference
Ag front6.00-16Reference
Ag front7.50-20 (4WD)Reference
Ag rear12.4-28Reference
Length299 cmReference
Height130 cmReference
2WD Weight1510 kgReference
4WD Weight1920 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
