Tractor · 1990Unverified
Fiat 35-66
Fiat 35-66 — 66 Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1400 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical front and rearReference
Power steeringReference
Wet disc brakesReference
Two-post fixed ROPS. Two-post folding mid-mount ROPS available.Reference
Engine
Lombardini 1.6L 3-cyl dieselReference
Fuel tank32.6 LReference
Engine25.7 kWReference
Lombardini LDW 1503Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.6 LReference
Bore/Stroke88 x 85 mmReference
Power25.7 kWReference
Compression17:1Reference
Rated RPM2800Reference
Torque102.0 NmReference
Torque RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears16 forward and reverseReference
Clutchdry discReference
Four synchronized gears in four ranges with shuttle.Reference
PTO & Hydraulics
Typeopen centerReference
Pump flow23.0 lpmReference
Rear TypeIIReference
Rear lift1375 kgReference
Rear PTOindependentReference
Clutchdry discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2276Reference
Engine RPM1000@2476Reference
Dimensions
Wheelbase169 cmReference
Weight1400 kgReference
Front tire5.50-16Reference
Rear tire11.2R28Reference
Ag front5.50-16 (2WD)Reference
Ag front250/80-18 (4WD)Reference
Ag rear11.2R28 (2WD)Reference
Ag rear320/70R28 (4WD)Reference
Length316 cmReference
Width137 cmReference
Height (ROPS)199 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Speeds
With 11.2R28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
