Tractor · 1971Unverified
Fiat 355C
Fiat 355C — 55 Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2229 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Open operator station.Reference
Engine
Fiat 2.3L 3-cyl dieselReference
Engine25.7 kWReference
Fiat 8035Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke95 x 110 mmReference
Power25.7 kWReference
Starter typeelectricReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear lift1200 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@2120Reference
Dimensions
Wheelbase129 cmReference
Weight2229 kgReference
10-inch tracksReference
Length246 cmReference
Width118 cmReference
Height (hood)112 cmReference
Height (exhaust)160 cmReference
Ground clearance24 cmReference
Gauge89 cmReference
Fiat 355C Tracks
Width25 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
